TKBA 20 SKF V Kayış Kasnak Hizalama Ayar Cihazı
TECHNICAL DATA TKBA 20
Designation
TKBA 20
Type of laser
Green laser diode
Laser
1x Built-in class 2 laser, <1 mW, 532 nm
Laser line length
2 m at 2 m (6.6 ft at 6.6 ft)
Measurement accuracy angular
Better than 0,02° at 2 m (6.6 ft)
Measurement accuracy offset
Better than 0,5 mm (0.02 in.)
Measurement distance
50 mm to 6 000 mm (2 in. to 20 ft)
Control
Laser on/off rocker switch
Housing material
Aluminum, powder coat finish
Dimensions
Transmitter unit
169 x 51 x 37 mm (6.65 x 2.0 x 1.5 in.)
Receiver unit
169 x 51 x 37 mm (6.5 x 2.0 x 1.5 in.)
Reflector dimensions
22 x 32 mm (0.9 x 1.3 in.)
Weight
Transmitter unit 365 g (0.8 lbs)
Receiver unit 340 g (0.7 lbs)
Mounting Magnetic, side mounted
V-guides N/A
Battery 2x AAA Alkaline type IEC LR03
Operation time 8 hours continuous operation
Carrying case dimensions 260 x 180 x 85 mm (10.2 x 7.1 x 3.3 in.)
Total weight (incl. case 1,3 kg (2.9 lbs)
Operating temperature 0 to 40 °C (32 to 104 °F)
Storage temperature –20 to +60 °C (–4 to +140 °F)
Relative humidity 10 to 90% RH non-condensing
IP rating IP 40
Calibration certificate Valid for two years
Case contents
1x TKBA 20 transmitter unit
1x TKBA 20 receiver unit
2x AAA batteries
1x Printed instructions for use
1x Calibration certificate
