Açıklama
General Specifications
UPC: | 726166054007 | Weight: | 0.64 LB |
Packaged Length: | 2.7 Inches | Packaged Width: | 1.4 Inches |
Packaged Height: | 2.6 Inches |
Technical Specifications
Sealing: | Sealed | O.D. Configuration: | Cylindrical |
Dynamic Track Roller Load Rating (N): | 28,440 N | Limiting Speed: | 2,200 |
Rolling Element: | Needle Roller – Full Complement | Relubricatable: | Yes |
Material: | Bearing Steel, Black Oxide Finish | Overall width – mm: | 25 mm |
Static Load Rating: | 13,197 | Tolerance Class: | P0 |
Roller Diameter – mm: | 52 mm | Roller Width – mm: | 24 mm |
Dynamic Load Rating – N: | 34,130 | Platform: | CAMROL® |
Roller Shape: | Cylindrical | Minimum Boss Diameter – mm: | 36 mm |
Static Track Roller Load Rating: | 58,700 | Bore Diameter – mm: | 25 mm |
